MagCAD Hammerhead Karoo 2 Canyon CP0018 Handlebar Mount
Mount your Hammerhead Karoo 2 computer in front of your Canyon CP0018 aerocockpit with this MagCAD Mount.
What's Included
- 1x 3D printed mount.
- 1x M4x20mm button head screw.
- 1x M4x12mm button head screw.
The Hammerhead Karoo device and Canyon handlebars pictured are for reference only and not included.
Overview
This mount is designed to integrate seamlessly with the latest Canyon CP0018 handlebars found on the Aeroad and new Ultimate.
The mount attaches to the two existing M4 threaded inserts on the underside of the Canyon CP0018 aerocockpit whilst matching the contoured surface of the handlebars. Your Hammerhead Karoo 2 device is held securely just in front of the handlebar leading edge, parallel to the stem.
Please note the version mount is not suitable for other Canyon handlebars such as the H31 & H36 aerocockpit. It is designed specifically for the CP0018 handlebars.
Application
Attach the mount to the underside of your Canyon CP0018 handlebars with the two M4 screws, supplied. The longer M4x20mm screw should be used in the front hole, the M4x12mm screw in the rear hole. We recommend using a thread locking compound and periodically checking the mount remains secure.
To attach your Hammerhead device simply follow the same procedure as with the OEM Hammerhead mount, pulling the device backward onto the mount with a slight twist to centre and locate it. You should here a positive click when the device is attached. We recommend using the tether that's supplied with your Hammerhead device just for extra security.
Compatible With:
- Hammerhead Karoo 2
- Canyon CP0018 Aerocockpit.
Specifications
- Weight: 32 grams (without hardware).
